| Article number | 3320.0859 |
|---|---|
| Catalog Number | G400-2LVE/C2/SV/F/30/EVH/0-4000(160)/AV2/O |
| Custom tarif number | 84135020 |
| Design | On tank assembly |
| Article number | 3320.0859 |
|---|---|
| Catalog Number | G400-2LVE/C2/SV/F/30/EVH/0-4000(160)/AV2/O |
| Custom tarif number | 84135020 |
| Design | On tank assembly |
| Mobility | Portable |
| Type / pressure generator | G400-2LVE |
| Fluid | Compressed air, Oil |
| Min. Drive pressure | 1 bar |
| Max. Drive pressure | 5 bar |
| Outlet pressure max. | 3,980 bar (57,700 psi) |
| Air control unit | C2 |
| Air safety valve | 5 bar |
| Number of outlets | 2 |
| Drive pressure PL | 8B - 1/2 BSPP with seal outside |
| Pressure outlet P | 4H - 1/4" Tube High Pressure |
| Pressure bleed | EVH - Pressure bleed manual |
| Pressure gauge | 0-4000 bar ø 160 mm |
| Dimensions (L x W x H) approx. | 520 x 570 x 1050 mm |
| Weight approx. | 66 kg |
